 Product Overview

LightBo's standard-type triple-digit 7-segment LED numeric display is engineered to deliver exceptional visibility with its ultra bright red emission, making it a standout choice for digital displays and indicators. Boasting a compact design with a 0.36-inch (9.2mm) digit height and outer dimensions of 22.50 x 14 x 7.2mm, it features crisp white segments on a sleek black

surface—ensuring clear readability even in well-lit environments. With a common cathode configuration, low power consumption, and stable performance, this display integrates effortlessly into a range of devices, from home appliances to instrument panels.

Main Product Image

Key Features

Ultra Bright Red Emission: Delivers vivid red light (620-625nm wavelength) with a luminous intensity of 70-90mcd, ensuring high visibility in diverse settings.

Compact & Precise Design: 0.36-inch (9.2mm) digit height and 22.50 x 14 x 7.2mm outer dimensions make it ideal for space-constrained applications.

Energy Efficiency: Low forward voltage (1.8-2.2V/LED) and forward current (5-10mA/LED) minimize power usage, reducing operational costs.

Stable Performance: Offers consistent illumination, good segment consistency, and reliable operation for long-term use.

Easy Integration: Compatible with ICs and simple to assemble, facilitating quick installation into digital indicators and appliances.

Versatile Color Options: Available in red, blue, yellow, green, pure green, white, amber, and orange to suit custom needs.

RoHS Compliant: Meets environmental standards, ensuring safety and sustainability.

Close-Up Detail Image

•


Origin	Shenzhen,China
Brand Name	LightBo
Type	Standard
Digit Count	Triple-digit
Digit Height	0.36 inch (9.2mm)
Outer Dimensions	22.50 x 14 x 7.2mm
Polarity	Common cathode
Emitting Color	Ultra bright red (multi-color options available)
Wavelength	620-625nm (red)
Luminous Intensity	70-90mcd
Forward Voltage	1.8-2.2V/LED
Forward Current	5-10mA/LED
Surface Design	White segments on black surface
Compliance	RoHS

      Applications

This versatile display is widely used in:

Digital displays and indicators

Home appliances (microwaves, ovens, etc.)

Instrument panels

Electronic devices requiring clear numeric readouts

     Order & Logistics

Minimum Order: 1000 pieces

Trade Term: EXW

Payment Terms: T/T, WU

Origin: Guangdong, China (Mainland)

Transport Options: Ocean, Air, Land

Production Capacity: 10,000 pcs/day

Packing: EPE + Carton (secure protection for transit)

Delivery Time: 5-7 days



Why Choose This Display?

With ultra bright red illumination, low power usage, and a compact form factor, it's designed to enhance readability in any application. Backed by LightBo's commitment to quality, it offers stable performance, easy assembly, and multi-color options—making it a reliable choice for both standard and custom projects.




• Office and Factory Overview:

•

•




• Company Exhibitions:

•

•

  Certifications:

•


     FAQ

     FAQ(Frequently Asked Questions)

Q1 Are you trading company or manufacturer?
A: We are original manufacturer with more than 20 years experience in optoelectronic LED displays .


Q2 What is your main products?
A: Our main products include 7 Segment LED display, SMD LED Display,Dot matrix LED Display, Arrow LED display, Custom Design LED Display ,LED light bar,Through hole led, SMD LEDs,LED Backlights, and so on .


Q3 What is your MOQ?
A: Our MOQ is 1000 pcs , We can also accept sample orders and small orders with quantity less than our MOQ .


Q4 Before placing order, Can I get some samples for test?
A: Yes. We can provide 5-10 free samples for your testing, but the freight cost will be borne by the customer.


Q5 How long is your delivery time?
A: Delivery time:About 10-20 days; According to order quantity and raw materials. If you have urgent order,and we have raw materials in stock,we can adjust our production plan to make it ready within 7-10 days .


Q6 What is your terms of payment?
A: We accept bank transfer,T/T,Western Union and Paypal with small amount. Detailes of payment methods can be negotiatble.


Q7 Can you quote me FOB prices?
A: Yes. We can quote you prices based on incoterms EXW, FOB, CIF,DDP.


Q8 How can I get your catalogue and price list?
A: Yes . Please let us know your email address or contact us from website directly for our catalogue and price list .


Q9 Can I negotiate the prices?
A: Yes, we may consider discounts for bulk orders.


Q10 How much will the shipping charges be?
A: It depends on the size of your shipment and the method of shipping.We will offer the charge to you as you requested.


Q11 Can you do custom design products?
A: Yes , OEM&ODM service are available .We can customize the sizes,led color and functional icons according to your requirements.


Q12 If I send my design , can you make it for myself only ,and will not show it to any one else?
A: Yes , we will not show it or sell to others without your authorization.


Q13 What will be the samples lead time for customized products?
A: Samples lead time will be about 20-25 working days after receiving mold cost and mold drawing approval from customers .


Q14 What is the shipping methods?
 A:We usually ship the goods by DHL, FEDEX,UPS,EMS,BY AIR,BY SEA etc, also you can choose the other way that best for you.


Q15 How do you ensure the quality of your products?
A: we are ISO 9001 QMS ceritified manufacturers with more than 20 years experience ,We conduct twice 100% percent test for all of our products before shipment.
















•
