Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller
Min. Order: 1000 Piece/Pieces
Payment Terms: T/T, WU
Place of Origin: Guangdong, China (Mainland)
Means of Transport: Ocean, Air, Land
Packing: epe+carton
Delivery Date: 5-7 days
Type: Standard
Brand Name: Light-Bo
Dimensions: 39*17.5*7.5mm
Polarity: Common Cathode
Emitting Color: Super bright red
Application: Temperature indicator
Custom 7 segment led display
Dimensions: 39*17.5*7.5mm
Emitting Color: Super bright red
Common cathode
Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller
  • Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller
  • Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller
  • Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller
  • Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller
  • Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller
  • Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller

Super Red  Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller

Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller

Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller

Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller

Super Red Common cathode Triple Digit 7 Segment LED Display with Minus sign for Temperature controller



Custom Super Red 7 Segment LED Display with minus sign for Digital Temperature Indicator


Custom Super Red 7 Segment LED Display with minus sign for Digital Temperature Indicator


Custom Super Red 7 Segment LED Display with minus sign for Digital Temperature Indicator




Custom Super Red 7 Segment LED Display for Digital Temperature Indicator



Triple Digit 7 segment led display with minus sign


Dimensions: 39*17.5*7.5mm



Polarity: Common Cathode


Emitting Color: Super bright red



Wavelength: 620-625nm



Luminous intensity: 60-70mcd



Forward voltage: 1.8-2.3V/LED



Forward current: 5-10mA/LED



High luminous intensity and reliability

Low power consumption

Stable performance

Contiunous uniform segments

Easy mounting on PCB

IC Compatible

Long lifetime

 RoHS Compliant

Various led color available .


  • Absolute Maximum Ratings(Ta=25ºC)

    ParameterSymbolRatingsUnit
    Forward Current(per dice)Ipm20mA
    Reverse Voltage(per dice)Vr5V
    Power Dissipation(per dice)Pm80mW
    Operating Temperature RangeTopr-40~+85ºC
    Storage Temperature RangeTstg-40~+85ºC
    Solder Temperature(≤3 seconds)Th260

    ºC


  •  LED color : Available in Red, blue,ice blue, green, white, amber, orange ,pink, violet


  • Optica/Electrical Characteristics


  • Code:Yellow Green- J

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA1.8
    2.4V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA30
    40mcd
    Spectrum With Of Half Value△λIf=10mA
    20
    nm
    WavelengthIf=10mA569
    574nm



    Code:Amber/Yellow -Y

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA1.8
    2.5V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA60
    80mcd
    Spectrum With Of Half Value△λIf=10mA
    20
    nm
    WavelengthIf=10mA585
    595nm




    Code:Orange -F

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA1.8
    2.4V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA60
    80mcd
    Spectrum With Of Half Value△λIf=10mA
    20
    nm
    WavelengthIf=10mA600
    605nm



    Code:Super Bright Red -R

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA1.8
    2.2V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA50
    60mcd
    Spectrum With Of Half Value△λIf=10mA
    20
    nm
    WavelengthIf=10mA630
    635nm



    Code:Ultra Bright Red -UR

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA1.8
    2.2V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA80
    100mcd
    Spectrum With Of Half Value△λIf=10mA
    20
    nm
    WavelengthIf=10mA625
    635nm



    Code:Pure Green -G

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA2.6
    3.2V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA120
    180mcd
    Spectrum With Of Half Value△λIf=10mA
    20
    nm
    WavelengthIf=10mA515
    525nm


    Code:Ultra Bright Blue -BH

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA2.8
    3.2V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA120
    140mcd
    Spectrum With Of Half Value△λIf=10mA
    20
    nm
    WavelengthIf=10mA460
    465nm
  • Code:Ultra Bright White -WH

    ParameterSymbolConditionMinTypMaxUnit
    Forward VoltageVfIf=10mA2.8
    3.2V
    Reverse VoltageVrIr=10uA5

    V
    Luminous IntenstyIvIf=10mA120
    140mcd
    LED color TemperatureKIf=10mA5500206800K

    Chromaticity Coordinates

    X/YIf=10mA0.29,0.32
    0.30,0.33nm




Application :  Widely used for digital temperature indicators,humidity indicators,home appliances, instrument panels and so on.
